G50A
Features
| Max. fluid temperature | 100 ℃ | 212 F |
| Valve type | Ball |
For more information, see our available downloads below or contact us!
Contact usSpecifications of G50A
Max. fluid
100 ℃ | 212 F
100 ℃ | 212 F
Valve type
Ball
Ball
Maximum capacity
670 liters/min (PTFE Diaphragm 640 L/min)
670 liters/min (PTFE Diaphragm 640 L/min)
Port size
50 mm | 2 "
50 mm | 2 "
-
Max. fluid temperature100 ℃ | 212 F
Valve typeBall
Maximum capacity670 liters/min (PTFE Diaphragm 640 L/min)
Port size50 mm | 2 "
Air Supply Pressure2 - 7 bar (0.2 - 0.7 MPa)
Discharge Volume per Cycle2400 mL
Maximum Size Solid8,0 mm or less
Maximum Dry Suction Lift3,5 m (PTFE Diaphragm 1,3 m)
Body materialAluminum (ADC-12)
Diaphragm materialHytrel® (H)
NBR (N)
PTFE (T)
Santoprene (S)
Air motorStandard: Aluminum
-
- G50AH00 KG50D-MH / KG50V-MH / KG50-MH / KG50-AM / KG50-AMS
- G50AN00 KG50D-MN / KG50V-MN / KG50-MN / KG50-AM / KG-50AMS
- G50AS00 KG50D-MS / KG50V-MS / KG50-MS / KG50-AM / KG50-AMS
- G50AT00 KG50D-MT / KG25V-MT / KG50-MT / KG50-AM / KG50-AMS
